| Fig. 1 |
Tadiran/ElbitHF modem, most likely the HF-6000 model, moving in COMSEC mode utilizing FSK 125Bd/300Hz Digital Coded Squelch (DCS) and scrambled voice-comms. The FSK segmentes (the DCS part) sent during the scrambled voice-comms have a velocity of 125Bd and 300Hz shift, i.e. same parameters of the first F7B (apparently MFSK-4) waveform, and cosists of a 160-bit period bitstream (Figure 2).
 |
| Fig. 2 - main DCS parameters |
It's worth note that the transmission was sent utilizing LSB (Figure 3).
 |
| Fig. 3 |
https://disk.yandex.com/d/novPamUmQksXmg
