The thought for this post came to me while talking with my friend ANgazu (from radiofrecuencias.es) about an emerging Spread Spectrum (SS) method that uses MultiCarrier waveforms (MC-SS).
The question that came up was whether the alleged "wideband" Akula (15 × 500Bd DBPSK) utilized this kind of spread spectrum technique, specifically a Filter Bank based multicarrier waveform (FBMC-SS).
I demodulated the 15 channels and found that they carry the same information carried by the following "usual" FSK 500Bd/1000 transmission (Figs. 1,2,3).
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEio4Dq7tSMfFMZWYJzmRuqyVRz_fNklqJ55AaLaOuXWyygkBXWSGCD0JYU69q5bFTz93k_tCysikARgDUIDEw4om6GOf-fPAYIpUhvebgw8QCfVLvAGVSFsp1ry_eAayBxm5-tz_cHpsDCOUiTL8bzagJ4IjmPn-TmVnpNijYeKeXpDo60zUFKIco9k5qg/w640-h568/a1.png) |
Fig. 1 - channels 1-6
|
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEiNkoGAXJkT2LYke5LwD8mihe2zyVysY3tj_N73EPWO9od0Zr0kjub3S0sW1pGz_4jQNXSdgzq56j7rdQw3Of_nhduVvlOxE7eOfXFaZKziXx8TQz5uoc4xSDFdfT116Tf7d-c8OG0dHNLfvx299nyJcVIcMBHYnZGB4_LQZgPeV41U5IK1ib3yJhCBZxQ/w640-h570/a2.png) |
Fig. 2 - channels 7-12
|
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEhtR4PWQeJevGSXnl3_SF27O3_h3yPBkHmLr2Uirs-_z6QdP8oLZ0mQ5pBxMT15cJkrrQzJWdtouQXbd3CH8PxsI_r4usM1XMz9_WJwDGch0Zq2DoKxYvluYyznG8vI6U0bLhmwv6tf8AS4juSNEox4porgVnYxEvdFVsTB_wEbZpOVtMQbzaOpimCCwQ4/w640-h576/a3.png) |
Fig. 3 - channels 13-15 and FSK segment
|
Channel separation is 2 Khz, rather adequate to let a easy detection and filtering of the subcarriers, for a full bandwidth of 30 KHz (Figure 4). As 1 can see, wideband Akula's spectrum is very different from another multicarrier waveforms like OFDM or mPSK (if only for the utilized bandwidth).
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEjMR6HA10atMbodCF6rUVc3Jh1D-2jpNSp3ks9rQRH8pt-vrHsDUgY5lkZm-nmmqm3CGLqzxEQGIK49R3jyfD96KZAF-gjhQoGd7F8WkeO-mvPNnwxc6FhJQJZT3va3Rb8VDVwGpkHfzP5DOrqIcFH2NuCaKBlpnHUgGYt_8nEMMrIU9ymgPLr7NnJ-BL0/w640-h384/1.PNG) |
Fig. 4 - wideband Akula and its spettral occupancy
|
Two popular spread spectrum systems in usage present are frequency-hopping spread spectrum (FH-SS) and direct-sequence spread spectrum (DS-SS). The basic thought of the multicarrier spread spectrum (MC-SS) is to transmit redundant information on multiple subcarriers with a slight phase variation on each one. The Filter Bank MultiCarrier Spread Spectrum (FBMC-SS) waveform, as its name implies, makes usage of a filter bank to make a spread spectrum technique. With this waveform, data symbols are spread across a number of non-overlapping adjacent subcarriers unlike in DS-SS, where spreading is performed across time, as it happens utilizing Walsh Direct series Spread Spectrum (Walsh DS-SS). The carriers are positioned in a way that the receiver can isolate a single channel by means of selective filtering without interchannel interference. 1 unique feature of this FBMC-SS construction is that it can easy mask portions of the band that are corrupted by interference or jamming intended by a foe: indeed, a narrow band interference stays well isolated and does not affect more than a fewer subcarriers (it is no coincidence that I heard wideband Akula utilizing a distant SpyServer receiver located in Ukraine).
I don't have the tools to say for certain that they usage a FBMC-SS waveform, but there are any elements that lead to this conclusion.
In the links below you can download, in addition to the signal and the channel demodulations, interesting documentation about FBMC-SS so that people more skilled than me can comment or deny our hypothesis.
